Multi Crystalline Solar Modules

-- 215W / 220W / 225W / 230W / 235W --

IO-Power Technology Multi Crystalline Solar Modules
Model Number	IOP-OSPMC-215368001	IOP-OSPMC-220368101	IOP-OSPMC-225368201	IOP-OSPMC-230368301	IOP-OSPMC-235378301
Specification	215W / 36.26V / 8.03A	220W / 36.46V / 8.12A	225W / 36.66V / 8.21A	230W / 36.86V / 8.30A	235W / 37.06V / 8.39A
Maximum Power Rating (W) ± 3%	215W	220W	225W	230W	235W
Open Circuit Voltage (Voc)	36.26V	36.46V	36.66V	36.86V	37.06V
Short Circuit Current (Isc)	8.03A	8.12A	8.21A	8.30A	8.39A
Maximum Power Voltage (Vmp)	28.70V	29.07V	29.44V	29.81V	30.18V
Maximum Power Current (Imp)	7.47A	7.55A	7.63A	7.72A	7.79A
Module Efficiency (%)	13.14%	13.44%	13.75%	14.05%	14.36%
Maximum System Voltage	1000VDC
Output Terminal	Cable with Tyco Connectors
Weight	18.8Kgs / 41.45lbs
Dimensions (L x W x H)	1655 x 989 x 39 mm (65.50” x 38.94” x 1.54”)
Number of Cells	60 in a 6 x 10 matrix connected in series
Solar Cell Type	Multi Crystalline Silicon
Solar Cell Size	6” / 156 x 156 mm
Temperature Coeff. of Voc	-0.34 %/K
Temperature Coeff. of Isc	0.06 %/K
Temperature Coeff. of Pmax	-0.40 %/K



















			STC: irradiance level 1000W/m2, spectrum AM 1.5 and Cell temperature 25℃

I I I I I I

IO-Power Technology Co., Ltd. 1F, No. 5, Neighbor 1, Chailin Vil., Xikou Township, Chiayi County 623, Taiwan Tel / Fax :+886 5 2697 986
