Multi Crystalline Solar Modules

-- 190W / 195W / 200W / 205W / 210W --

IO-Power Technology Multi Crystalline Solar Modules
Model Number	IOP-OSPMC-190328001	IOP-OSPMC-195328001	IOP-OSPMC-200328101	IOP-OSPMC-205338201	IOP-OSPMC-210338301
Specification	190W / 32.49V / 8.00A	195W / 32.69V / 8.09A	200W / 32.89V / 8.18A	205W / 33.09V / 8.27A	210W / 33.29V / 8.36A
Maximum Power Rating (W) ± 3%	190W	195W	200W	205W	210W
Open Circuit Voltage (Voc)	32.49V	32.69V	32.89V	33.09V	33.29V
Short Circuit Current (Isc)	8.00A	8.09A	8.18A	8.27A	8.36A
Maximum Power Voltage (Vmp)	25.57V	25.94V	26.31V	26.68V	27.05V
Maximum Power Current (Imp)	7.42A	7.51A	7.60A	7.69A	7.77A
Module Efficiency (%)	12.84%	13.18%	13.52%	13.86%	14.19%
Maximum System Voltage	1000VDC
Output Terminal	Cable with Tyco Connectors
Weight	17.5Kgs / 38.58lbs
Dimensions (L x W x H)	1496 x 989 x 39 mm (58.90” x 38.94” x 1.54”)
Number of Cells	54 in a 6 x 9 matrix connected in series
Solar Cell Type	Multi Crystalline Silicon
Solar Cell Size	6” / 156 x 156 mm
Temperature Coeff. of Voc	-0.34 %/K
Temperature Coeff. of Isc	0.06 %/K
Temperature Coeff. of Pmax	-0.40 %/K



















			STC: irradiance level 1000W/m2, spectrum AM 1.5 and Cell temperature 25℃

I I I I I I

IO-Power Technology Co., Ltd. 1F, No. 5, Neighbor 1, Chailin Vil., Xikou Township, Chiayi County 623, Taiwan Tel / Fax :+886 5 2697 986
